Wide Airflow

The thin, ceiling-concealed indoor units of the PEY series are the perfect answer for the air conditioning requirements of buildings with minimum ceiling installation space and wide-ranging external static pressure. Energy-saving efficiency has been improved, thereby reducing electricity consumption and contributing to a further reduction in operating cost.

Compact Indoor Units

For all models, unit height are unified to 250mm. Compared to the previous model, the height size is reduced, allowing installation in tight spaces, such as ceiling cavities or drop-ceilings.

Air Inlet

The units with bottom inlet make more noise than those with rear inlet. It is recommended that the rear inlet be selected when install - ing the units in the rooms that should be quiet such as bedrooms.

Wide Selection of Fan Speeds and External Static Pressure

Five-stage external static pressure conversions and three fan speed selections are available. Capable of being set to a maxi -mum of 125Pa, units are applicable to a wide range of building types.
